CU/MICA/XLPE/SWA/LSHF Fire Resistant Cable, Two Core, 35mm, 0.6/1kV | Alfanar
(1232 Product Views)
CU/MICA/XLPE/SWA/LSHF Fire Resistant Cable, 2 core, 35 mm2 , 0.6/1kV, it is sheathed with an outer layer of a low smoke halogen-free compound (LSHF), minimizes smoke and toxic fumes in case of fire, it is suitable for use in fixed installations, in areas where smoke and acid gas evolution could pose a hazard to personnel or sensitive equipment, from Alfanar Cables Company.
Product description
Fire resistant armoured power cable (CU/MICA/XLPE/SWA/LSHF). Produced by Alfanar Cables Company. Armored with single layer of galvanized steel wires (SWA) to give it mechanical strength to protect it from external pressures that fall on the cable. Insulated with XLPE (cross-linked polyethylene) which provides a unique combination of strength, flexibility and reliability making them suitable for a diverse range of applications. It can withstand high temperatures up to 90°C for extended periods without compromising performance. The cable also withstands harsh environmental conditions, including moisture, corrosion and chemicals, making it ideal for outdoor use. Chloride-free, making it environmentally friendly. Also, it is sheathed with an outer layer of a low smoke halogen-free compound (LSHF), minimizes smoke and toxic fumes in case of fire, therefore, it is suitable for use in fixed installations, in applications where maintenance of power supply during a fire is required for a defined period of time such as for essential safety circuits, fire alarm systems and sprinkler systems, etc., in areas where smoke and acid gas evolution could pose a hazard to personnel or sensitive equipment in high-rise buildings, schools, hospitals, hotels, shopping centers, subways, etc. Available in various shapes and sizes in highest quality and best prices to suit different applications and needs.
- Conductor Type: Copper
- Conductor Shape: Stranded Circular (rm)
- Fire Resistant Barrier: Mica Glass Tape (MICA)
- Insulation Material: XLPE (Cross-Linked Polyethylene)
- Bedding: LSHF
- Armouring: Single Layer of Galvanized Steel Wires (SWA)
- Outer Jacket: LSHF (Low Smoke Halogen Free)
- Voltage: 600/1000 volts
- Number of Cores: 2
- Conductor Size (Cross-Sectional Area): 35 mm2
- Max DC Conductor Resistance at 20°C: 0.5240 ohm/km
- Max AC Conductor Resistance at 90°C: 0.6687 ohm/km
- Current Rating Laid in Ground: 180 Ampere
- Current Rating Laid in Ducts: 138 Ampere
- Current Rating Laid in Free Air: 188 Ampere
- Approx Overall Diameter: 28.5 mm
- Weight: 1945 kg/km
- Phase Core Colors: (Red, Black)
- Standard: IEC 60502-1
