6 AWG Stranded THHN Copper Electrical Wire, 600 Voltage Rating, PVC Insulated, Nylon Jacketed, Orange Color, 250 ft Length | Alfanar

Product description

THHN stranded copper electrical wire, manufactured by Alfanar Company. Insulated with polyvinyl chloride (PVC) and jacketed with nylon for added protection against abrasion and scratches during conduit pulling. It also offers good resistance to oil, gasoline, and chemicals. THHN building wires are used in dry locations for general applications such as power and lighting in residential and commercial buildings. Common applications include wiring appliances, control panels, and motors.

• Conductor : Stranded Copper
• Insulation Material: Polyvinyl Chloride (PVC) 105 ºC
• Jacket: Nylon
• Voltage: 600 volts
• Conductor Size (Cross-Sectional Area): 13.3 mm2 (6 AWG)
• Number of Wires x Diameter: 19 × 0.944 mm
• Max DC Conductor Resistance at 20°C: 1.348 ohm/km
• Nominal Insulation Thickness: 0.76 mm
• Normal Jacket Thickness: 0.13 mm
• Approx Overall Diameter: 6.4 mm
• Weight: 195 kg/km
• Insulation Color: Orange
• Length: 250 feet
