3 Core 25mm2 0.6/1kV Fire Resistant Cable, Copper Wire, LSHF Sheathed | Alfanar

Product description

Fire resistant power cable (CU/MICA/XLPE/LSHF). 3 core stranded copper conductor, Produced by Al Fanar Company according to IEC 60502-1 (International Electrotechnical Commission) standard. Insulated with XLPE (cross-linked polyethylene) which provides a unique combination of strength, flexibility and reliability making them suitable for a diverse range of applications. It can withstand high temperatures up to 90°C for extended periods without compromising performance. The cable also withstands harsh environmental conditions, including moisture, corrosion and chemicals, making it ideal for outdoor use. Chloride-free, making it environmentally friendly. Also, it is sheathed with an outer layer of a low smoke halogen-free compound (LSHF), minimizes smoke and toxic fumes in case of fire, therefore, it is suitable for use in fixed installations, in applications where maintenance of power supply during a fire is required for a defined period of time such as for essential safety circuits, fire alarm systems and sprinkler systems, etc., in areas where smoke and acid gas evolution could pose a hazard to personnel or sensitive equipment in high-rise buildings, schools, hospitals, hotels, shopping centers, subways, etc. Available in various shapes and sizes in highest quality and best prices to suit different applications and needs.

• Conductor Type: Copper
• Fire Resistant Barrier: Mica Glass Tape (MICA)
• Insulation Material: XLPE (Cross-Linked Polyethylene)
• Outer Jacket: LSHF (Low Smoke Halogen Free)
• Voltage: 600/1000 volts
• Conductor Shape: Round Stranded (rm)
• Number of Cores: 3
• Conductor Size (Cross-Sectional Area): 25 mm2
• Max DC Conductor Resistance at 20°C: 0.7270 ohm/km
• Max AC Conductor Resistance at 90°C: 0.9274 ohm/km
• Current Rating Laid in Ground: 126 Ampere
• Current Rating Laid in Ducts: 92 Ampere
• Current Rating Laid in Free Air: 126 Ampere
• Approx Overall Diameter: 22.5 mm
• Weight: 1010 kg/km
• Phase Core Colors: (Red, Yellow, Blue)
• Standard: IEC 60502-1
