Alfanar 630 sq mm Single Electrical Wire 450/750V, Stranded Copper Conductor PVC Insulation 2.8mm Thickness
(482 Product Views)
Stranded copper electrical cable (CU/PVC), 630 mm2 cross-sectional area, 450/750 volts, phase core color is gray, making it suitable for wiring in lighting networks, power systems. Available in various shapes and sizes in highest quality and best prices to suit different applications and needs, produced by Alfanar Company.
Product description
Stranded copper electrical wire (CU/PVC), manufactured by Alfanar Company in accordance with the latest BS or IEC standards. Insulated with polyvinyl chloride (PVC 70 ºC),They are distinguished by their economical cost, reliable performance, and durability, As it is forms excellent insulation around the conductor to prevent leakage of electric current, protection for the wire against shocks, and abrasion. It also prevents harmful UV rays from damaging the cable and it is also highly resistant to water and moisture. Intended for fixed internal installations, making it suitable for wiring in control boards, machines and instruments with higher operating temperature, and in lighting networks, power systems. Available in various shapes and sizes in highest quality and best prices to suit different applications and needs.
- Conductor Type: Copper
- Conductor Shape: Stranded
- Insulation Material: Polyvinyl Chloride (PVC) 70 ºC
- Voltage: 450/750 volts
- Conductor Size (Cross-Sectional Area): 630 mm
- Number of Wires: 61
- Conductor Diameter: 3.81 mm
- Max DC Conductor Resistance at 20°C: 0.0283 ohm/km
- Nominal Insulation Thickness: 2.8 mm
- Approx Overall Diameter: 35.7 mm
- Weight: 6098 kg/km
- Length: 100 yards on Coil (Other lengths available on request)
- Color: Gray
- Standard: BS EN 50525-2-31, IEC 60227-3 and SASO-GSO-IEC 60227-3 standards
