4 mm2, 450/750V stranded copper wire insulated with heat-resistant PVC, ideal for industrial and commercial applications where high levels of safety and performance are required. Provides protection against moisture and UV rays. Yellow/Green color. Produced by Alfanar.

in stock
general.mada
general.master_card
general.visa
general.tamara

Product description

Stranded copper electrical heat resistant wire (CU/PVC) manufactured by Alfanar, in accordance with the latest British Standards (BS) and International Electrotechnical Commission (IEC) standards. Insulated with polyvinyl chloride (PVC 90 ºC), they are distinguished by their economical cost, reliable performance, and durability. The insulation forms an excellent layer around the conductor to prevent electric current leakage and provides protection against shocks, abrasion, and corrosion. It also prevents harmful UV rays from damaging the cable and is highly resistant to water and moisture. Intended for fixed internal installations, making it suitable for wiring in control boards, machines, and instruments with higher operating temperatures, as well as in lighting networks and power systems. Available in various shapes and sizes with the highest quality and best prices to suit different applications and needs.

  • Conductor Type: Copper
  • Conductor Shape: Stranded
  • Insulation Material: (PVC 90 ºC) Heat Resistant
  • Voltage: 450/750 volts
  • Conductor Size (Cross-Sectional Area): 4 mm²
  • Number of Wires: 7
  • Conductor Diameter: 0.85 mm
  • Max DC Conductor Resistance at 20°C: 4.61 ohm/km
  • Nominal Insulation Thickness: 0.8 mm
  • Approx Overall Diameter: 4.2 mm
  • Weight: 50 kg/km
  • Length: 300 feet on Coil (100 yards). Other lengths available on request
  • Color: Yellow/Green
  • Standard: BS EN 50525-2-31, IEC 60227-3 and SASO-GSO-IEC 60227-3 standards
