14 AWG Solid Copper THHN American Wire, 600 V, PVC Insulated, Nylon Jacketed, Blue Color, Coil Length 300ft | Alfanar
(511 Product Views)
14 AWG Solid Copper THHN American Wire, 600 V, insulated with PVC and jacketed with nylon to protect the insulation from abrasion and scratches during pulling and installation. The wire is ideal for power and lighting in residential and commercial buildings, offering high resistance to oils and chemicals, making it suitable for use in dry locations with high temperatures. Blue color. Produced by Alfanar.
Product description
THHN solid copper electrical wire, manufactured by Alfanar. Insulated with polyvinyl chloride (PVC) and jacketed with nylon for added protection against abrasion and scratches during conduit pulling. It also offers good resistance to oil, gasoline, and chemicals. THHN building wires are commonly used in general applications to provide power and lighting in residential and commercial buildings in dry locations subject to continuous high temperatures.
- Wire Type: (THHN 105°C) for dry locations, building wire
- Conductor: Solid Copper
- Insulation Material: PVC (Polyvinyl Chloride) 105 °C
- Jacket: Polyamide Nylon
- Voltage: 600 volts
- Conductor Size (Cross-Sectional Area): 2.08 mm² (14 AWG)
- Number of Wires: 1 × 1.63 mm
- Max DC Conductor Resistance at 20°C: 8.45 ohm/km
- Nominal Insulation Thickness: 0.38 mm
- Normal Jacket Thickness: 0.10 mm
- Overall Diameter: 2.7 mm
- Weight: 24 kg/km
- Insulation Color: Blue
- Standard Length: 300 feet on coil (Other lengths available on request)
- Standard: UL 83
