14 AWG Stranded THHN Copper Electric Wire, 600 V, PVC Insulated, Nylon Jacketed, Orange Color, 250 ft Length | Alfanar
(353 Product Views)
THHN stranded copper electrical wire, size 14 AWG, rated at 600 volts, insulated with polyvinyl chloride (PVC), insulation color orange, manufactured by Alfanar Company.
Product description
THHN stranded copper electrical wire, manufactured by Alfanar Company. Insulated with polyvinyl chloride (PVC) and jacketed with nylon for added protection against abrasion and scratches during conduit pulling. It also offers good resistance to oil, gasoline, and chemicals. THHN building wires are used in dry locations for general applications such as power and lighting in residential and commercial buildings. Common applications include wiring appliances, control panels, and motors.
- Conductor : Stranded Copper
- Insulation Material: Polyvinyl Chloride (PVC) 105 ºC
- Jacket: Nylon
- Voltage: 600 volts
- Conductor Size (Cross-Sectional Area): 2.08 mm2 (14 AWG)
- Number of Wires x Diameter: 19 × 0.37 mm
- Max DC Conductor Resistance at 20°C: 8.62 ohm/km
- Nominal Insulation Thickness: 0.38 mm
- Normal Jacket Thickness: 0.10 mm
- Approx Overall Diameter: 2.9 mm
- Weight: 24 kg/km
- Insulation Color: Orange
- Length: 250 feet
