Flat Pipe Flange Size 4 inch, Thickness 22 mm, Union Pipes Factory
(247 Product Views)

Pipe Flange Size 4 inch, Thickness 22 mm, Produced By Union Pipes Factory ensuring long-lasting performance even in harsh conditions. It is the perfect choice for connecting hot and cold water pipes, as well as for sewage systems.
-
About Product
Product description
Flange produced by Union Pipe Factory, made of high-quality materials, characterized by strength, durability, resistance to rust and corrosion, ease of installation and the ability to withstand high pressure, which makes it suitable for wide use in connecting hot and cold water pipes, as well as in sewage systems, available in a variety of sizes and at the best prices.
- Size : 4 inch
- Nominal diameter (dn): 125B mm
- Outer diameter (D): 230 mm
- Spacing between holes (K): 191 mm
- Ring width (B): 140 mm
- Thickness (h): 22 mm
- Number of holes (n): 8
- Hole diameter (d): 20 mm
- Weight: 2.14 kg
- Class: 150
- According to standard: ASME B16.5
